Intel BD82QM77
The Intel BD82QM77 is a mobile chipset for LGA 1155 sockets, released in 2012 as part of the Panther Point-M family.
The Intel BD82QM77 is a mobile chipset designed for LGA 1155 sockets, released on April 8, 2012. It is built on a 32 nm process with a TDP of 4.1 W. The chipset supports DDR3/L/-RS memory at 1333/1600 MHz, with a maximum capacity of 16 GB across two channels. It provides 8 PCIe 2.0 lanes and uses DMI 2.0 for connectivity to the processor. Storage includes 2 SATA III ports, while USB connectivity offers 4 USB 3.2 Gen 1 ports and 10 USB 2.0 ports. The chipset includes an integrated MAC for Ethernet, but lacks Thunderbolt, Wi-Fi, and Bluetooth. It supports Intel Rapid Storage Technology and vPro, but does not support CPU or memory overclocking. Compatible form factors include BGA and PGA. The BD82QM77 is the successor to the QM67 and was succeeded by the QM87.
Specifications
| Socket unverified | LGA 1155 |
|---|---|
| Platform unverified | Mobile |
| Process node unverified | 32 nm |
| TDP unverified | 4.1 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 2 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 4 |
| USB 2.0 ports unverified | 10 |
| Thunderbolt support unverified | No |
| Integrated Ethernet unverified | Integrated MAC |
| Integrated Wi-Fi unverified | No |
| Integrated Bluetooth unverified | No |
| Intel Rapid Storage Technology unverified | Yes |
| vPro support unverified | Yes |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) unverified | No |
| Supported form factors unverified | BGA, PGA |
| Release date unverified | 2012-04-08 |
| Release year unverified | 2012 |
| Successor unverified | QM87 |
| Predecessor unverified | QM67 |
| Notes unverified | Part of Panther Point-M chipset family |
