Intel · 2012
Intel BD82UM77
The Intel BD82UM77 is a mobile chipset for Ivy Bridge processors, released in 2012.
The Intel BD82UM77 is a Platform Controller Hub (PCH) designed for the Ivy Bridge platform, released on April 8, 2012. It uses a 22 nm process node and has a TDP of 3.0 W. The chipset supports LGA 1155 socket processors and provides 4 PCIe 2.0 lanes, DMI 2.0 interface, and dual-channel DDR3 memory up to 16 GB without ECC support. It includes 4 SATA III ports, 4 USB 3.2 Gen 1 ports, and 6 USB 2.0 ports. The UM77 is intended for mobile systems, offering a balance of connectivity and low power consumption.
Specifications
| Socket unverified | LGA 1155 |
|---|---|
| Platform unverified | Ivy Bridge |
| Process node unverified | 22 nm |
| TDP unverified | 3.0 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 4 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 3.2 Gen 1 ports unverified | 4 |
| USB 2.0 ports unverified | 6 |
| Release date unverified | 2012-04-08 |
| Release year unverified | 2012 |
