Intel · 2015
Intel C232
The Intel C232 is a server chipset for LGA 1151 sockets, released in 2015 on a 22 nm process with 6 W TDP.
The Intel C232 is a server chipset introduced in September 2015 for LGA 1151 sockets. It is built on a 22 nm process with a thermal design power of 6 W. The chipset supports DDR4-2133 memory with ECC, up to 64 GB across two channels. It provides 8 PCIe 3.0 lanes, 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 12 USB 2.0 ports. The C232 does not support Intel Rapid Storage Technology, CPU overclocking, or memory overclocking. It is designed for server platforms and pairs with Intel Xeon E3-1200 v5 processors.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Server |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-2133 |
| Max memory unverified | 64 GB |
| Memory channels unverified | 2 |
| ECC memory support | Yes |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 12 |
| Intel Rapid Storage Technology | No |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Launch MSRP | 34 USD |
