Intel C236
The Intel C236 is a server chipset for LGA 1151, released in 2015. It supports DDR4 ECC memory and Xeon E3-1200 v5/v6 processors.
The Intel C236 is a chipset released in 2015 for the LGA 1151 socket, targeting server platforms. It is built on a 22 nm process with a TDP of 6 W. The chipset supports DDR4 memory with a maximum capacity of 64 GB across two channels, including ECC memory support. It provides 20 PCIe 3.0 lanes and uses DMI 3.0 for chipset-to-CPU connectivity. Storage options include 8 SATA III ports, and connectivity includes 10 USB 3.2 Gen 1 ports and 14 USB 2.0 ports. The C236 supports Intel Rapid Storage Technology and vPro, but does not allow CPU or memory overclocking. It is designed for use with Xeon E3-1200 v5/v6 processors and also compatible with Core i7-6700K.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Server |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels unverified | 2 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Notes unverified | Chipset for Xeon E3-1200 v5/v6 and Core i7-6700K etc. |
