Intel · 2015
Intel CM236
The Intel CM236 is a mobile chipset for LGA 1151 sockets, released in 2015. It supports DDR4 memory with ECC and offers 20 PCIe 3.0 lanes.
The Intel CM236 is a mobile chipset released in 2015 for LGA 1151 sockets. It is built on a 22 nm process with a TDP of 3.67 W. The chipset supports DDR4 memory with up to 64 GB across two channels, including ECC memory support. It provides 20 PCIe 3.0 lanes and uses DMI 3.0 for CPU connection. Storage options include 8 SATA III ports, and connectivity features 10 USB 3.2 Gen 1 and 14 USB 2.0 ports. Integrated Ethernet MAC is included. The CM236 supports Intel Rapid Storage Technology and vPro, but does not support CPU or memory overclocking. It was launched with an MSRP of $50.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Mobile |
| Process node | 22 nm |
| TDP | 3.67 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Launch MSRP | 50 USD |
