Intel · 2013
Intel DH82H81
The Intel DH82H81 is a desktop chipset released in 2013 for LGA 1150 sockets, supporting DDR3 memory and featuring integrated Ethernet MAC.
The Intel DH82H81 (H81) is a chipset released in June 2013 for desktop platforms. It uses the LGA 1150 socket and supports DDR3 memory at 1333/1600 MHz with a maximum capacity of 16 GB across two channels. The chipset has a TDP of 4.1 W and provides six PCIe 2.0 lanes. It includes four SATA III ports, two USB 3.2 Gen 2 ports, and eight USB 2.0 ports. The H81 chipset integrates an Ethernet MAC but does not support Intel Rapid Storage Technology, CPU overclocking, or memory overclocking (XMP/EXPO). It is designed for use with compatible LGA 1150 processors.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Desktop |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 6 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels | 2 |
| ECC memory support unverified | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2 ports | 2 |
| USB 2.0 ports | 8 |
| Integrated Ethernet | MAC |
| Intel Rapid Storage Technology | No |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2013-06 |
| Release year | 2013 |
| Launch MSRP | 26 USD |
