Intel DH82H87
The Intel DH82H87 is a Lynx Point chipset for LGA 1150 sockets, released in 2013.
The Intel DH82H87 (H87) is a chipset part of the Lynx Point platform, designed for LGA 1150 sockets. It was released in June 2013 and built on a 32 nm process with a TDP of 4.1 W. The chipset supports DDR3 memory with two channels and a maximum capacity of 32 GB, but does not support ECC memory. It provides 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports, with no USB 3.2 Gen 2 support. The chipset features 8 PCIe 2.0 lanes and DMI 2.0 interface. It includes Intel Rapid Storage Technology. The H87 chipset is typically paired with 4th generation Intel Core processors (Haswell) and is used in mainstream desktop motherboards.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform unverified | Lynx Point |
| Process node | 32 nm |
| TDP unverified | 4.1 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 32 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 6 |
| USB 2.0 ports unverified | 8 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2013-06 |
| Release year unverified | 2013 |
