Intel DH82HM86
The Intel DH82HM86 is a mobile chipset for LGA 1150 sockets, released in 2013.
The Intel DH82HM86 is a mobile chipset designed for LGA 1150 sockets, launched in June 2013 with an MSRP of $48. It was discontinued in October 2015. Fabricated on a 32 nm process, it has a TDP of 2.7 W. The chipset supports DDR3 memory with a maximum capacity of 16 GB across two channels, without ECC support. It provides 8 PCIe 2.0 lanes and uses DMI 2.0 for CPU communication. Storage connectivity includes 4 SATA III ports. USB support consists of 5 USB 3.2 Gen 1 ports and 8 USB 2.0 ports, with no USB 3.2 Gen 2 ports. Intel Rapid Storage Technology is supported. This chipset is intended for use with LGA 1150 mobile processors.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Mobile |
| Process node | 32 nm |
| TDP | 2.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 5 |
| USB 2.0 ports | 8 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2013-06 |
| Release year unverified | 2013 |
| Discontinued | 2015-10 |
| Launch MSRP | 48 USD |
