Intel DH82Q85
The Intel DH82Q85 is a desktop chipset for LGA 1150 sockets, part of the Lynx Point family released in 2013.
The Intel DH82Q85 is a desktop chipset released in June 2013 as part of the Lynx Point family. It uses a 65 nm process node and has a TDP of 4.1 W. The chipset supports LGA 1150 sockets and is compatible with Haswell and Haswell Refresh CPUs. It features PCIe 2.0 with 8 chipset lanes and DMI 2.0. Memory support includes DDR3 800/1066 in dual-channel configuration, with a maximum capacity of 16 GB; ECC memory is not supported. Storage connectivity includes 6 SATA III ports. USB ports include 4 USB 3.2 Gen 1 and 10 USB 2.0 ports; no USB 3.2 Gen 2 or Gen 2x2 ports are available. The chipset supports vPro but does not support Intel Rapid Storage Technology, CPU overclocking, or memory overclocking (XMP/EXPO). Note that the C1 stepping has a USB 3.0 S3 sleep bug.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Desktop |
| Process node unverified | 65 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 800/1066 |
| Max memory unverified | 16 GB |
| Memory channels | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 2x2 ports | 0 |
| USB 3.2 Gen 2 ports | 0 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 10 |
| Intel Rapid Storage Technology | No |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2013-06 |
| Release year | 2013 |
| Notes unverified | Part of Lynx Point chipset family; supports Haswell/Haswell Refresh CPUs; C1 stepping has USB 3.0 S3 sleep bug |
