Intel DH82Q87
The Intel DH82Q87 is a mobile chipset for LGA 1150 sockets, released in 2013.
The Intel DH82Q87 is a mobile platform chipset designed for LGA 1150 sockets, manufactured on a 32 nm process with a TDP of 2.7 W. It supports DDR3 memory up to 32 GB across two channels, including ECC memory. The chipset provides 8 PCIe 2.0 lanes and features DMI 2.0 interconnect. It includes 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports, but lacks USB 3.2 Gen 2, Thunderbolt, and integrated Ethernet. It supports Intel Rapid Storage Technology and vPro. The DH82Q87 was released in June 2013 and discontinued in December 2015.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Mobile |
| Process node | 32 nm |
| TDP | 2.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 32 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | Yes |
| SATA III ports | 6 |
| USB 3.2 Gen 2x2 ports | 0 |
| USB 3.2 Gen 2 ports | 0 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 8 |
| Thunderbolt support | No |
| Integrated Ethernet | No |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Release date | 2013-06 |
| Release year | 2013 |
| Discontinued | 2015-12 |
