Intel · 2013
Intel DH82QM87
The Intel DH82QM87 is a mobile chipset released in 2013, built on a 32 nm process with a TDP of 2.7 W.
The Intel DH82QM87 is a mobile chipset introduced in 2013. It is fabricated on a 32 nm process and has a thermal design power (TDP) of 2.7 W. The chipset supports PCI Express 2.0 with 8 total lanes, 6 SATA III ports, 6 USB 3.2 Gen 2 ports, and 8 USB 2.0 ports. It includes Intel Rapid Storage Technology and vPro support. The DH82QM87 was discontinued in 2015.
Specifications
| Process node | 32 nm |
|---|---|
| TDP | 2.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| SATA III ports | 6 |
| USB 3.2 Gen 2 ports | 6 |
| USB 2.0 ports | 8 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Release date | 2013-04-01 |
| Release year | 2013 |
| Discontinued | 2015-10-01 |
