Intel DH82Z87
The Intel DH82Z87 is a Lynx Point chipset for LGA 1150 sockets, released in 2013. It supports DDR3 memory and provides 6 SATA III ports.
The Intel DH82Z87 (Z87) is a chipset part of the Lynx Point platform, designed for LGA 1150 sockets. It was released in June 2013 and manufactured on a 32 nm process with a TDP of 4.1 W. The chipset supports DDR3 memory with a maximum capacity of 32 GB across two channels, but does not support ECC memory. It provides 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. The chipset offers 8 PCIe 2.0 lanes and uses DMI 2.0 for communication with the CPU. It includes Intel Rapid Storage Technology and supports CPU overclocking.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform unverified | Lynx Point |
| Process node | 32 nm |
| TDP unverified | 4.1 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 32 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 6 |
| USB 2.0 ports unverified | 8 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking unverified | Yes |
| Release date unverified | 2013-06 |
| Release year unverified | 2013 |
