Intel · 2005
Intel E7230
The Intel E7230 is a chipset for LGA 775 processors, released in July 2005. It supports DDR2 memory, including ECC, and pairs with the ICH7/ICH7R south bridge.
The Intel E7230 is a chipset introduced in July 2005 for LGA 775 processors. It provides 8 PCIe 1.0a lanes and supports FSB speeds of 533, 800, and 1066 MT/s. The chipset supports dual-channel DDR2 memory at 400, 533, and 667 MHz, with up to 8 GB and ECC functionality. It is designed for Pentium D, Pentium 4 (including HT and EE), and Celeron D processors. The E7230 uses either the ICH7 or ICH7R south bridge, depending on configuration.
Specifications
| Socket | LGA 775 |
|---|---|
| PCIe version | 1.0a |
| Total PCIe lanes (chipset) unverified | 8 |
| Memory support | DDR2 400/533/667 |
| Max memory | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support | Yes |
| Release date unverified | 2005-07 |
| Release year | 2005 |
| Notes unverified | South bridge: ICH7/ICH7R; FSB: 533/800/1066 MT/s; Processor brands: Pentium D, Pentium 4, Pentium 4 HT, Pentium 4 EE, Celeron D |
