Intel · 2015
Intel GL82C232
The Intel GL82C232 is a server chipset for LGA 1151 platforms, released in 2015.
The Intel GL82C232 is a server chipset designed for LGA 1151 sockets, released in September 2015 with a launch MSRP of $34. It is fabricated on a 22 nm process with a TDP of 6 W. The chipset supports DDR4 memory with a maximum capacity of 64 GB across two channels, including ECC memory support. It provides 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 12 USB 2.0 ports, but lacks USB 3.2 Gen 2x2 and Gen 2 ports. It offers 8 PCIe 3.0 lanes and features a DMI 3.0 interface to the CPU. The chipset includes an integrated MAC for Ethernet but does not support Intel Rapid Storage Technology or memory overclocking (XMP/EXPO).
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Server |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | Yes |
| SATA III ports | 6 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 6 |
| USB 2.0 ports | 12 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Launch MSRP | 34 USD |
