Intel · 2015
Intel GL82C236
The Intel GL82C236 is a Platform Controller Hub (PCH) chipset for LGA 1151 sockets, released in 2015 as part of the Sunrise Point platform.
The Intel GL82C236 is a Platform Controller Hub (PCH) chipset designed for LGA 1151 sockets, released in 2015 as part of the Sunrise Point platform. It is fabricated on a 22 nm process with a TDP of 6 W. The chipset supports DDR4-2133 memory with up to 64 GB across two channels, including ECC memory support. It provides 20 PCIe 3.0 lanes and connects to the CPU via DMI 3.0. Storage connectivity includes 8 SATA III ports. USB support comprises 10 USB 3.2 Gen 1 ports and 14 USB 2.0 ports, with no USB 3.2 Gen 2 or Gen 2x2 ports. The chipset integrates an Ethernet MAC but lacks integrated Wi-Fi, Bluetooth, and Thunderbolt. It supports Intel Rapid Storage Technology and vPro, but does not support CPU or memory overclocking.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform unverified | Sunrise Point |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-2133 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | Yes |
| SATA III ports | 8 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Thunderbolt support unverified | No |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi unverified | No |
| Integrated Bluetooth unverified | No |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
