Intel · 2014
Intel GS40
The Intel GS40 is a desktop chipset released in 2014, supporting LGA1150 sockets and DDR3 memory.
The Intel GS40 is a desktop chipset released in April 2014 and discontinued in July 2017. It is designed for the FCLGA1150 socket and built on a 22 nm process node with a TDP of 35 W. The chipset provides 16 PCIe 3.0 lanes and supports up to 32 GB of DDR3-1333/1600 or DDR3L-1333/1600 memory across two channels, including ECC memory. It is intended for use with compatible Intel processors from the same era.
Specifications
| Socket | FCLGA1150 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 35 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 16 |
| Memory support | DDR3-1333/1600, DDR3L-1333/1600 |
| Max memory | 32 GB |
| Memory channels | 2 |
| ECC memory support | Yes |
| Release date | 2014-04-01 |
| Release year | 2014 |
| Discontinued | 2017-07-14 |
