Intel H110
The Intel H110 is a desktop chipset for LGA 1151, released in 2015. It supports DDR4 memory and provides basic connectivity for budget systems.
The Intel H110 is a desktop chipset released on September 27, 2015, with a launch MSRP of $26. It uses the LGA 1151 socket and is built on a 22 nm process with a TDP of 6 W. The chipset supports DDR4 memory up to 32 GB across two channels, but does not support ECC memory. It provides 4 SATA III ports, 4 USB 3.2 Gen 1 ports, and 10 USB 2.0 ports. PCIe connectivity is limited to version 2.0 with 6 lanes from the chipset, and DMI 3.0 connects to the CPU. Integrated Ethernet is supported via an integrated MAC. Intel Rapid Storage Technology is enabled, but CPU overclocking and memory overclocking (XMP/EXPO) are not supported. The H110 is the successor to the H81 and was succeeded by the H310.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 6 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 32 GB |
| Memory channels unverified | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 10 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-27 |
| Release year | 2015 |
| Launch MSRP | 26 USD |
| Successor unverified | H310 |
| Predecessor unverified | H81 |
