Intel H170
The Intel H170 is a desktop chipset for LGA 1151 sockets, released in 2015. It supports DDR3L/DDR4 memory and offers 6 SATA III ports.
The Intel H170 is a desktop chipset released in 2015, designed for LGA 1151 sockets. It is built on a 22 nm process with a TDP of 6 W. The chipset provides 16 PCIe 3.0 lanes and uses DMI 2.0 for communication with the CPU. It supports up to 64 GB of DDR3L or DDR4 memory across two channels, without ECC support. Storage connectivity includes 6 SATA III ports, and it offers 8 USB 3.2 Gen 1 ports and 14 USB 2.0 ports. Intel Rapid Storage Technology is supported, but CPU and memory overclocking are not. The H170 is typically paired with Intel Core processors of the Skylake generation (6th Gen) and is now discontinued.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 16 |
| DMI version | 2.0 |
| Memory support unverified | DDR3L/DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Notes | Discontinued |
