Intel H270
The Intel H270 is a desktop chipset for LGA 1151 sockets, released in 2017. It supports DDR4 memory and provides 20 PCIe 3.0 lanes.
The Intel H270 is a desktop chipset released in 2017, designed for LGA 1151 sockets. It is built on a 22 nm process with a TDP of 6 W. The chipset supports DDR4 memory with a maximum capacity of 64 GB across two channels, but does not support ECC memory or memory overclocking (XMP/EXPO). It provides 20 PCIe 3.0 lanes and uses DMI 3.0 to connect to the CPU. Storage options include 6 SATA III ports, while USB connectivity offers 8 USB 3.2 Gen 1 ports and 14 USB 2.0 ports, with no USB 3.2 Gen 2 support. The H270 includes Intel Rapid Storage Technology but does not support CPU overclocking. It features an integrated MAC but no wireless MAC. This chipset is intended for use with Intel's 7th generation Core processors (Kaby Lake) and is now discontinued.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2017-01-03 |
| Release year | 2017 |
| Discontinued | Discontinued |
| Notes | Integrated MAC, no wireless MAC |
