Intel H772
The Intel H772 is a desktop chipset for LGA 1155 sockets, released in 2012. It supports Intel Rapid Storage Technology and integrates 10/100/1000 Ethernet.
The Intel H772 is a desktop chipset released in 2012 for LGA 1155 sockets. It is built on a 65 nm process with a TDP of 6.7 W. The chipset provides 8 PCIe 2.0 lanes and uses DMI 2.0 for communication with the processor. It offers 6 SATA III ports, 4 USB 3.2 Gen 1 ports, and 10 USB 2.0 ports. Integrated 10/100/1000 Ethernet is supported. It also includes Intel Rapid Storage Technology. The H772 is designed for use with Intel Core processors of the Sandy Bridge and Ivy Bridge generations.
Specifications
| Socket unverified | LGA 1155 |
|---|---|
| Platform | Desktop |
| Process node | 65 nm |
| TDP | 6.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | DMI 2.0 |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 10 |
| Integrated Ethernet | 10/100/1000 Ethernet Support |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
