Intel H81
The Intel H81 is a desktop chipset for LGA 1150 sockets, released in 2013. It supports DDR3 memory and offers basic connectivity features.
The Intel H81 (code name Lynx Point) is a chipset for desktop platforms using the LGA 1150 socket, released in June 2013. It has a TDP of 4.1 W and supports DDR3 memory with two channels and a maximum capacity of 16 GB. ECC memory is not supported. The chipset provides 4 SATA III ports, 2 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. It features PCIe 2.0 with 6 total lanes and DMI 2.0. Integrated Ethernet is available via MAC. The H81 does not support Intel Rapid Storage Technology, CPU overclocking, or memory overclocking (XMP/EXPO). It also lacks PCIe M.2 support. FDI (Flexible Display Interface) is supported. The chipset was discontinued and had a launch MSRP of $26.00.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Desktop |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 6 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 16 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 1 ports | 2 |
| USB 2.0 ports | 8 |
| Integrated Ethernet | MAC |
| Intel Rapid Storage Technology | No |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2013-06 |
| Release year | 2013 |
| Discontinued | Discontinued |
| Launch MSRP | 26.00 USD |
| Notes unverified | Code name: Lynx Point; FDI support: Yes; PCIe M.2 support: No |
