Intel H97
The Intel H97 is a desktop chipset for LGA 1150 sockets, released in May 2014. It supports DDR3 memory and features 6 SATA III ports and 6 USB 3.2 Gen 1 ports.
The Intel H97 is a desktop chipset introduced in May 2014 as part of the 9 Series chipset family. It uses the LGA 1150 socket and is designed for mainstream desktop systems. The chipset has a TDP of 4.1 W and supports DDR3 memory. It provides 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. The H97 includes 8 PCIe 2.0 lanes and uses DMI 2.0 for communication with the processor. It integrates an Ethernet MAC and supports Intel Rapid Storage Technology. This chipset is typically paired with 4th and 5th generation Intel Core processors (Haswell and Broadwell). The H97 is now discontinued.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Desktop |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | DMI 2.0 |
| Memory support unverified | DDR3 |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 8 |
| Integrated Ethernet | MAC |
| Intel Rapid Storage Technology | Yes |
| Release date | 2014-05 |
| Release year | 2014 |
| Discontinued | Discontinued |
