Intel HM170
The Intel HM170 is a mobile chipset for LGA 1151 processors, released in 2015. It supports DDR4-2133 memory and PCIe 3.0.
The Intel HM170 is a mobile chipset designed for LGA 1151 processors, introduced in September 2015. It is built on a 22 nm process with a TDP of 2.6 W. The chipset provides 16 PCIe 3.0 lanes and supports up to 64 GB of DDR4-2133 memory across two channels, without ECC support. It includes 4 SATA III ports, 8 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. The HM170 features an integrated MAC for Ethernet, Intel Rapid Storage Technology, and supports CPU and memory overclocking (XMP/EXPO). It does not support Thunderbolt or USB 3.2 Gen 2/2x2. The chipset communicates with the processor via DMI 3.0. Its launch MSRP was $48.00.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Mobile |
| Process node | 22 nm |
| TDP | 2.6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 16 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-2133 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Thunderbolt support unverified | No |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date unverified | 2015-09-01 |
| Release year | 2015 |
| Launch MSRP | 48.00 USD |
