Intel · 2020
Intel HM470
The Intel HM470 is a mobile chipset for LGA 1200 sockets, released in 2020. It supports DDR4-2933 memory, Intel Wi-Fi 6, and CPU/memory overclocking.
The Intel HM470 is a mobile chipset introduced in 2020 for LGA 1200 sockets. It has a TDP of 3 W and supports DDR4-2933 memory with a maximum capacity of 128 GB across two channels, without ECC support. The chipset provides 16 PCIe 3.0 lanes, 4 SATA III ports, and multiple USB ports: 4 USB 3.2 Gen 2, 8 USB 3.2 Gen 1, and 14 USB 2.0. It integrates Intel Wi-Fi 6 AX201 and supports Intel Rapid Storage Technology. Both CPU and memory overclocking (XMP/EXPO) are enabled. The HM470 is designed for use with Intel mobile processors in the LGA 1200 package.
Specifications
| Socket unverified | LGA 1200 |
|---|---|
| Platform | Mobile |
| TDP | 3 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 16 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-2933 |
| Max memory unverified | 128 GB |
| Memory channels unverified | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2 ports | 4 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Integrated Wi-Fi | Intel Wi-Fi 6 AX201 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date | 2020-04-01 |
| Release year | 2020 |
