Intel · 2010
Intel HM55
The Intel HM55 is a mobile chipset released in 2010 for the Ibex Peak-M platform, supporting DDR3 memory and featuring 4 SATA III ports.
The Intel HM55 is a mobile chipset introduced in January 2010 as part of the Ibex Peak-M platform. It is designed for use with Intel processors in the mPGA-989 socket. The chipset is manufactured on a 45 nm process with a TDP of 3.5 W. It supports up to 8 GB of DDR3 memory at speeds of 1066/1333 MHz across two channels, without ECC support. The HM55 provides 6 PCIe 2.0 lanes and uses DMI 1.0 for connection to the processor. It includes 4 SATA III ports and 12 USB 2.0 ports, but lacks USB 3.2 Gen 1 support.
Specifications
| Socket unverified | mPGA-989 |
|---|---|
| Platform unverified | Ibex Peak-M |
| Process node unverified | 45 nm |
| TDP unverified | 3.5 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 6 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR3-1066/1333 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 12 |
| Release date unverified | 2010-01 |
| Release year unverified | 2010 |
