Intel · 2010
Intel HM57
The Intel HM57 is a mobile chipset for LGA 1156 processors, released in 2010. It supports DDR3 memory and features Intel Rapid Storage Technology.
The Intel HM57 (Ibex Peak-M) is a Platform Controller Hub (PCH) for mobile platforms, designed for LGA 1156 processors. Fabricated on a 45 nm process, it has a TDP of 3.5 W. The chipset provides 6 SATA III ports and 14 USB 2.0 ports, but lacks USB 3.2 Gen 1 support. It supports up to 8 GB of DDR3 memory across two channels, without ECC support. The HM57 includes Intel Rapid Storage Technology and allows CPU and memory overclocking (XMP/EXPO). It connects to the CPU via DMI 1.0 and provides 8 PCIe 2.0 lanes. FDI support enables integrated graphics output.
Specifications
| Socket unverified | LGA 1156 |
|---|---|
| Platform | Mobile |
| Process node unverified | 45 nm |
| TDP unverified | 3.5 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 1.0 |
| Memory support unverified | DDR3 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support | No |
| SATA III ports unverified | 6 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 14 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date unverified | 2010-01 |
| Release year unverified | 2010 |
| Notes unverified | Code name: Ibex Peak-M; sSpec: SLGZR(B3); Part number: BD82HM57 (PCH); FDI support: Yes |
