Intel · 2021
Intel HM570E
The Intel HM570E is a mobile chipset for Tiger Lake platforms, released in 2021.
The Intel HM570E is a chipset designed for Tiger Lake platforms, released in July 2021. It uses a BGA 1787 socket and is built on a 10 nm process with a TDP of 2.9 W. The chipset provides 16 PCIe 3.0 lanes and supports DMI 3.0. It supports up to 64 GB of DDR4-3200 memory across two channels, without ECC support. Storage connectivity includes 4 SATA III ports. For USB, it offers 8 USB 3.2 Gen 2 ports, 8 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. It integrates an Ethernet MAC and an Intel Wireless-AC MAC for Wi-Fi. Intel Rapid Storage Technology is supported, but memory overclocking (XMP/EXPO) is not. The launch MSRP was $56.
Specifications
| Socket unverified | BGA 1787 |
|---|---|
| Platform unverified | Tiger Lake |
| Process node unverified | 10 nm |
| TDP | 2.9 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 16 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-3200 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2 ports | 8 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wireless-AC MAC |
| Intel Rapid Storage Technology | Yes |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2021-07-01 |
| Release year | 2021 |
| Launch MSRP | 56 USD |
