Intel · 2011
Intel HM65
The Intel HM65 is a mobile chipset for Socket G2/G3, released in 2011. It supports DDR3-1333 memory and provides 6 SATA III ports.
The Intel HM65 is a mobile chipset introduced in 2011, designed for use with Intel's second-generation Core processors (Sandy Bridge) in laptops. It uses the 32 nm process and has a TDP of 3.9 W. The chipset supports up to 16 GB of DDR3-1333 memory across two channels, without ECC support. It provides 6 SATA III ports and 12 USB 2.0 ports, but lacks USB 3.0. It includes Intel Rapid Storage Technology but does not support vPro or CPU/memory overclocking. The HM65 connects to the CPU via DMI 2.0 and offers 8 PCIe 2.0 lanes. It is available in BGA and rPGA form factors. It succeeded the HM55 and was later replaced by the HM76.
Specifications
| Socket unverified | Socket G2 (rPGA988B) / Socket G3 (BGA1023) |
|---|---|
| Platform | Mobile |
| Process node unverified | 32 nm |
| TDP unverified | 3.9 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3-1333 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 6 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports unverified | 12 |
| Intel Rapid Storage Technology unverified | Yes |
| vPro support unverified | No |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) unverified | No |
| Supported form factors unverified | BGA, rPGA |
| Release date unverified | 2011-01-09 |
| Release year unverified | 2011 |
| Successor unverified | HM76 |
| Predecessor unverified | HM55 |
