Intel · 2011
Intel HM67
The Intel HM67 is a mobile chipset for Socket G2, released in 2011. It supports DDR3-1333 memory and provides PCIe 2.0 connectivity.
The Intel HM67 is a mobile chipset introduced in 2011 for Socket G2 platforms. It is fabricated on a 32 nm process with a TDP of 3.9 W. The chipset supports up to 16 GB of dual-channel DDR3-1333 memory without ECC. It features 8 PCIe 2.0 lanes and a DMI 2.0 interface. Storage connectivity includes 2 SATA III ports, while USB support is limited to 14 USB 2.0 ports. The HM67 is designed for use with Intel's second-generation Core processors (Sandy Bridge) in mobile systems.
Specifications
| Socket unverified | Socket G2 |
|---|---|
| Platform | Mobile |
| Process node unverified | 32 nm |
| TDP unverified | 3.9 W |
| PCIe version unverified | 2.0 |
| Total PCIe lanes (chipset) unverified | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3-1333 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 2 |
| USB 2.0 ports unverified | 14 |
| Release date unverified | 2011-01-09 |
| Release year unverified | 2011 |
