Intel · 2012
Intel HM70
The Intel HM70 is a mobile chipset released in 2012, designed for use with Intel processors in laptops and other portable devices.
The Intel HM70 is a mobile chipset introduced in 2012, built on a 22 nm process with a TDP of 4.1 W. It supports DDR3/L/-RS memory up to 16 GB across two channels, and features PCIe 2.0 with 8 lanes. The chipset includes one SATA III port, four USB 3.2 Gen 1 ports, and six USB 2.0 ports. It supports Intel Rapid Storage Technology and uses DMI 2.0 for communication with the processor. The HM70 is designed for the BGA 1023 socket and is intended for use with Intel's mobile processors.
Specifications
| Socket unverified | BGA 1023 |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 1 |
| USB 3.2 Gen 1 ports unverified | 4 |
| USB 2.0 ports | 6 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
