Intel · 2012
Intel HM75
The Intel HM75 is a mobile chipset released in 2012, supporting DDR3 memory and featuring Intel Rapid Storage Technology.
The Intel HM75 is a mobile chipset released on April 8, 2012. It uses a BGA 1023 socket and is built on a 22 nm process with a TDP of 4.1 W. The chipset supports DDR3/L/-RS memory at 1333/1600 MHz, with a maximum capacity of 16 GB across two channels, and does not support ECC memory. It provides six SATA III ports, twelve USB 2.0 ports, and eight PCIe 2.0 lanes. The DMI version is 2.0. Intel Rapid Storage Technology is supported. This chipset is designed for mobile platforms and is typically paired with compatible Intel processors.
Specifications
| Socket unverified | BGA 1023 |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 2.0 ports | 12 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
