Intel · 2012
Intel HM76
The Intel HM76 is a mobile chipset released in 2012, designed for Socket G2 processors.
The Intel HM76 is a mobile chipset introduced on April 8, 2012, for Socket G2 processors. It is built on a 22 nm process with a TDP of 4.1 W. The chipset supports DDR3/L/-RS memory at 1333/1600 MHz, up to 16 GB across two channels, without ECC support. It provides 6 SATA III ports, 4 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. The HM76 features 8 PCIe 2.0 lanes and DMI 2.0 interface. It includes Intel Rapid Storage Technology. This chipset is intended for use with compatible Intel mobile processors.
Specifications
| Socket unverified | Socket G2 |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 8 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
