Intel · 2012
Intel HM77
The Intel HM77 is a mobile chipset released in 2012, supporting Socket G2 and DDR3 memory.
The Intel HM77 is a mobile chipset introduced in 2012 for use with Socket G2 processors. It is manufactured on a 22 nm process with a TDP of 4.1 W. The chipset provides 8 PCIe 2.0 lanes and supports DMI 2.0. Memory support includes DDR3/L/-RS at 1333/1600 MHz, up to 16 GB across two channels, without ECC support. Storage connectivity includes 6 SATA III ports, while USB connectivity offers 4 USB 3.2 Gen 1 ports and 10 USB 2.0 ports. Intel Rapid Storage Technology is supported. The HM77 succeeded the HM65 and was followed by the HM87.
Specifications
| Socket unverified | Socket G2 |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 10 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
| Discontinued | 2012 |
| Launch MSRP | 48 USD |
| Successor unverified | HM87 |
| Predecessor unverified | HM65 |
