Intel HM770
The Intel HM770 is a mobile chipset for Raptor Lake processors, released in 2023. It supports DDR5-5600 and DDR4-3200 memory, PCIe 4.0, and features integrated Wi-Fi 6E and Bluetooth 5.3.
The Intel HM770 is a mobile chipset introduced in 2023 for the Raptor Lake platform. It uses a 10 nm process node and has a TDP of 3.7 W. The chipset supports up to 96 GB of memory across two channels, with options for DDR5-5600 or DDR4-3200. It does not support ECC memory. The HM770 provides 28 PCIe 4.0 lanes and uses a DMI 4.0 interface to the processor. It includes 8 SATA III ports, 4 USB 3.2 Gen 2x2 ports, 10 USB 3.2 Gen 2 ports, 10 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. Thunderbolt 4 is supported. The chipset integrates an Intel Wi-Fi 6E AX211 module and Bluetooth 5.3, along with an integrated MAC for Ethernet. It supports Intel Rapid Storage Technology, CPU overclocking, and memory overclocking (XMP/EXPO). vPro is not supported. The HM770 is designed for mobile form factors and had a launch MSRP of $54.
Specifications
| Socket unverified | BGA 1744 |
|---|---|
| Platform unverified | Raptor Lake |
| Process node unverified | 10 nm |
| TDP | 3.7 W |
| PCIe version | 4.0 |
| Total PCIe lanes (chipset) | 28 |
| DMI version | 4.0 |
| Memory support unverified | DDR5-5600, DDR4-3200 |
| Max memory unverified | 96 GB |
| Memory channels unverified | 2 |
| ECC memory support | No |
| SATA III ports | 8 |
| USB4 ports unverified | 0 |
| USB 3.2 Gen 2x2 ports | 4 |
| USB 3.2 Gen 2 ports | 10 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Thunderbolt support unverified | 4 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6E AX211 |
| Integrated Bluetooth unverified | 5.3 |
| Intel Rapid Storage Technology | Yes |
| vPro support | No |
| CPU overclocking | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Supported form factors | Mobile |
| Release date unverified | 2023-01-03 |
| Release year | 2023 |
| Launch MSRP | 54 USD |
