Intel · 2013
Intel HM86
The Intel HM86 is a mobile chipset released in 2013, part of the Lynx Point-M family, supporting 4th generation Core processors.
The Intel HM86 (Lynx Point-M) is a mobile chipset introduced in June 2013 for 4th generation Core processors. It uses a 32 nm process with a TDP of 2.7 W and connects via BGA 1364. The chipset provides 8 PCIe 2.0 lanes, 6 SATA III ports, 5 USB 3.2 Gen 1 ports, and 10 USB 2.0 ports. It supports up to 16 GB of DDR3L memory at 1333/1600 MHz across two channels, without ECC. Intel Rapid Storage Technology is included. The HM86 was discontinued in December 2015, with a launch MSRP of $43.
Specifications
| Socket unverified | BGA 1364 |
|---|---|
| Platform | Mobile |
| Process node | 32 nm |
| TDP | 2.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3L 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports unverified | 5 |
| USB 2.0 ports | 10 |
| Intel Rapid Storage Technology | Yes |
| Release date unverified | 2013-06 |
| Release year | 2013 |
| Discontinued | 2015-12 |
| Launch MSRP | 43 USD |
| Notes | Discontinued; code name Lynx Point-M |
