Intel · 2013
Intel HM87
The Intel HM87 is a mobile chipset released in 2013, designed for 4th generation Core processors.
The Intel HM87 is a mobile chipset introduced in June 2013, built on a 32 nm process with a TDP of 2.7 W. It supports PCIe 2.0 with 8 chipset lanes and DMI 2.0. The chipset provides 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. It includes Intel Rapid Storage Technology but lacks integrated Ethernet. The HM87 is intended for use with 4th generation Intel Core processors (Haswell) in laptops and mobile workstations. It was discontinued in December 2015 with a launch MSRP of $48.
Specifications
| Socket | N/A |
|---|---|
| Platform | Mobile |
| Process node | 32 nm |
| TDP | 2.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 8 |
| Integrated Ethernet | No |
| Intel Rapid Storage Technology | Yes |
| Release date | 2013-06 |
| Release year | 2013 |
| Discontinued | 2015-12 |
| Launch MSRP | 48 USD |
