Intel HM97
The Intel HM97 is a desktop chipset for LGA 1150 sockets, released in 2014. It supports DDR3-1600 memory and features 6 SATA III and 6 USB 3.2 Gen 1 ports.
The Intel HM97 is a 22 nm desktop chipset introduced in May 2014 for LGA 1150 sockets. It has a TDP of 4.1 W and supports DDR3-1600 memory with a maximum capacity of 32 GB across two channels. ECC memory is not supported. The chipset provides 8 PCIe 2.0 lanes and uses DMI 2.0 for CPU communication. It includes 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. Intel Rapid Storage Technology is supported. The HM97 is designed for use with Intel Core processors of the Haswell generation.
Specifications
| Socket unverified | LGA 1150 |
|---|---|
| Platform | Desktop |
| Process node unverified | 22 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3-1600 |
| Max memory unverified | 32 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 8 |
| Intel Rapid Storage Technology | Yes |
| Release date | 2014-05 |
| Release year | 2014 |
| Discontinued | Discontinued |
