Intel ICH6
The Intel ICH6 is a southbridge chip released in 2004, part of Intel's chipset family for Pentium 4 and Celeron processors.
The Intel ICH6 (I/O Controller Hub 6) is a southbridge chip released in 2004, designed to work with Intel's 915 and 925 series chipsets. It connects to the northbridge via a Direct Media Interface (DMI). The ICH6 supports 8 USB 2.0 ports, 4 SATA III ports, and 8 PCIe 2.0 lanes. It is manufactured on a 65 nm process with a TDP of 3.8 W. The chipset is compatible with Pentium 4 and Celeron processors using LGA775 socket.
Specifications
| Process node | 65 nm |
|---|---|
| TDP unverified | 3.8 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 8 |
| Release year unverified | 2004 |
