Intel PM45
The Intel PM45 is a mobile chipset for Socket P, part of the Cantiga platform, released in July 2008.
The Intel PM45 is a chipset designed for mobile platforms, using the Socket P interface. It is part of the Cantiga platform and was released in July 2008. The chipset is built on a 65 nm process and has a thermal design power (TDP) of 7 W. It supports PCIe 1.0 with 16 lanes. Memory support includes DDR2 at 667/800 MHz and DDR3 at 800/1066 MHz, with a maximum capacity of 8 GB across two channels. ECC memory is not supported. The chipset provides 4 SATA III ports and 12 USB 2.0 ports. It is typically paired with Intel Core 2 Duo and Core 2 Quad mobile processors from the same era.
Specifications
| Socket unverified | Socket P |
|---|---|
| Platform unverified | Cantiga |
| Process node unverified | 65 nm |
| TDP unverified | 7 W |
| PCIe version unverified | 1.0 |
| Total PCIe lanes (chipset) unverified | 16 |
| Memory support unverified | DDR2 667/800, DDR3 800/1066 |
| Max memory unverified | 8 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports unverified | 4 |
| USB 2.0 ports unverified | 12 |
| Release date unverified | 2008-07 |
| Release year unverified | 2008 |
