Intel Q150
The Intel Q150 is a desktop chipset for LGA 1151 sockets, released in 2015. It supports DDR3L/DDR4 memory and features 6 SATA III ports and 8 USB 3.2 Gen 1 ports.
The Intel Q150 is a desktop chipset released in 2015 for LGA 1151 sockets (rev 1). It is built on a 22 nm process with a TDP of 6 W. The chipset provides 10 PCIe 3.0 lanes and supports DMI 3.0. Memory support includes DDR3L and DDR4 with a maximum capacity of 64 GB across two channels, but ECC memory is not supported. It offers 6 SATA III ports, 8 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. Intel Rapid Storage Technology is supported, but CPU and memory overclocking are not. The Q150 is designed for business-oriented desktop systems and is now discontinued.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 10 |
| DMI version | 3.0 |
| Memory support unverified | DDR3L/DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2015-09-01 |
| Release year | 2015 |
| Notes | Discontinued; LGA 1151 rev 1 chipset |
