Intel · 2015
Intel Q170
The Intel Q170 is a 2015 desktop chipset for LGA 1151 rev 1 sockets, supporting DDR3L/DDR4 memory and featuring 20 PCIe 3.0 lanes.
The Intel Q170 is a desktop chipset released in October 2015, designed for LGA 1151 rev 1 sockets. It is built on a 22 nm process with a TDP of 6 W. The chipset supports up to 64 GB of dual-channel DDR3L or DDR4 memory without ECC support. It provides 20 PCIe 3.0 lanes, 6 SATA III ports, 10 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. It includes Intel Rapid Storage Technology and vPro support, but does not support CPU or memory overclocking. The chipset features an integrated MAC for Ethernet and comes in a 23mm x 23mm form factor. It is used with Intel Skylake and Kaby Lake processors on LGA 1151 rev 1 motherboards.
Specifications
| Socket unverified | LGA 1151 rev 1 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR3L/DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Supported form factors | 23mm x 23mm |
| Release date | 2015-10 |
| Release year | 2015 |
| Launch MSRP | 47 USD |
