Intel Q250
The Intel Q250 is a desktop chipset for LGA 1151 sockets, released in 2017. It supports DDR3L/DDR4 memory and Intel Optane Memory.
The Intel Q250 is a desktop chipset for LGA 1151 sockets, released in 2017. It is built on a 22 nm process with a TDP of 6 W. The chipset provides 14 PCIe 3.0 lanes and a DMI 3.0 interface to the CPU. It supports up to 64 GB of DDR3L/DDR4 memory across two channels, without ECC support. Storage connectivity includes 6 SATA III ports. USB connectivity offers 8 USB 3.2 Gen 1 ports and 14 USB 2.0 ports. The chipset includes Intel Rapid Storage Technology and supports Intel Optane Memory. CPU and memory overclocking are not supported. The Q250 is designed for use with Intel processors in the LGA 1151 rev 1 socket.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 14 |
| DMI version | 3.0 |
| Memory support unverified | DDR3L/DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2017-01-03 |
| Release year | 2017 |
| Notes | LGA 1151 rev 1 chipset; supports Intel Optane Memory |
