Intel · 2017
Intel Q270
The Intel Q270 is a desktop chipset for LGA 1151 sockets, released in 2017. It supports DDR4 memory, Intel vPro, and Rapid Storage Technology.
The Intel Q270 is a desktop chipset introduced on January 3, 2017, for LGA 1151 sockets (revision 1). It is built on a 22 nm process with a TDP of 6 W. The chipset provides 24 PCIe 3.0 lanes and a DMI 3.0 interface to the CPU. Memory support includes dual-channel DDR4 with a maximum capacity of 64 GB; ECC memory is not supported. Storage connectivity includes 6 SATA III ports. USB connectivity offers 10 USB 3.2 Gen 1 ports and 14 USB 2.0 ports. Features include Intel Rapid Storage Technology and Intel vPro support. CPU overclocking and memory overclocking (XMP/EXPO) are not supported. The Q270 is a discontinued chipset designed for business-oriented desktop platforms.
Specifications
| Socket unverified | LGA 1151 |
|---|---|
| Platform | Desktop |
| Process node | 22 nm |
| TDP | 6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 24 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels unverified | 2 |
| ECC memory support | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date unverified | 2017-01-03 |
| Release year | 2017 |
| Notes | Discontinued; LGA 1151 rev 1 chipset |
