Intel QM175
The Intel QM175 is a mobile chipset released in 2017, designed for Intel's 7th and 8th generation Core processors.
The Intel QM175 is a mobile chipset introduced in 2017, built on a 22 nm process with a TDP of 2.6 W. It supports DDR4 memory up to 64 GB across two channels and features PCIe 3.0 with 16 chipset lanes. The chipset includes 4 SATA III ports, 8 USB 3.2 Gen 1 ports, and 14 USB 2.0 ports. It has an integrated MAC for Ethernet, supports Intel Rapid Storage Technology and vPro, and allows memory overclocking (XMP/EXPO). The QM175 uses a BGA 1440 socket and is intended for use with compatible mobile processors.
Specifications
| Socket unverified | BGA 1440 |
|---|---|
| Platform | Mobile |
| Process node | 22 nm |
| TDP | 2.6 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 16 |
| DMI version | 3.0 |
| Memory support unverified | DDR4 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 1 ports | 8 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Memory overclocking (XMP/EXPO) | Yes |
| Release date unverified | 2017-01-03 |
| Release year | 2017 |
| Launch MSRP | 48 USD |
