Intel · 2020
Intel QM480
The Intel QM480 is a mobile chipset for Comet Lake processors, released in 2020. It supports DDR4-2933 memory and features integrated Wi-Fi 6 and Bluetooth 5.1.
The Intel QM480 is a mobile chipset designed for Comet Lake processors, released in April 2020. It uses a BGA 1528 socket and is built on a 14 nm process with a TDP of 3 W. The chipset provides 20 PCIe 3.0 lanes and supports DDR4-2933 memory up to 128 GB across two channels, without ECC support. It includes four SATA III ports, six USB 3.2 Gen 2 ports, ten USB 3.2 Gen 1 ports, and fourteen USB 2.0 ports. The QM480 integrates an Intel Wi-Fi 6 AX201 adapter and Bluetooth 5.1, along with an integrated MAC for Ethernet. It supports Intel Rapid Storage Technology and vPro, but does not support CPU overclocking. Memory overclocking via XMP is supported. This chipset is intended for use with Comet Lake mobile processors.
Specifications
| Socket | BGA 1528 |
|---|---|
| Platform unverified | Comet Lake |
| Process node | 14 nm |
| TDP | 3 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support | DDR4-2933 |
| Max memory | 128 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB4 ports | 0 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports | 6 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Thunderbolt support | No |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6 AX201 |
| Integrated Bluetooth | 5.1 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | Yes |
| Supported form factors | Mobile |
| Release date | 2020-04-01 |
| Release year | 2020 |
| Notes | Mobile chipset for Comet Lake processors. |
