Intel · 2021
Intel QM580
The Intel QM580 is a mobile chipset for Tiger Lake platforms, released in 2021 on a 10 nm process with a 3.4 W TDP.
The Intel QM580 is a mobile chipset designed for Tiger Lake platforms, released in April 2021 with a launch MSRP of $54. It is built on a 10 nm process and has a TDP of 3.4 W. The chipset supports DDR4-3200 memory up to 64 GB across two channels, without ECC support. It provides 20 PCIe 3.0 lanes and uses DMI 3.0 for CPU connectivity. Storage options include 4 SATA III ports, and connectivity features 10 USB 3.2 Gen 2 ports, 10 USB 3.2 Gen 1 ports, 14 USB 2.0 ports, and Thunderbolt 4 support. Integrated networking includes an Intel MAC for Ethernet and Intel Wi-Fi 6 AX201. The chipset supports Intel Rapid Storage Technology and vPro, but does not allow CPU or memory overclocking. It was discontinued in April 2023.
Specifications
| Socket unverified | BGA 1498 |
|---|---|
| Platform unverified | Tiger Lake |
| Process node unverified | 10 nm |
| TDP | 3.4 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support unverified | DDR4-3200 |
| Max memory unverified | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2 ports | 10 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Thunderbolt support unverified | 4 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wi-Fi 6 AX201 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2021-04-01 |
| Release year | 2021 |
| Discontinued | 2023-04-01 |
| Launch MSRP | 54 USD |
