Intel · 2021
Intel QM580E
The Intel QM580E is an embedded chipset for Tiger Lake platforms, released in 2021 with a TDP of 2.9 W.
The Intel QM580E is an embedded chipset designed for Tiger Lake platforms, released in July 2021 with a launch MSRP of $56. It uses a BGA 1787 socket and has a TDP of 2.9 W. The chipset supports up to 64 GB of DDR4-3200 memory across two channels, without ECC support. It provides 20 PCIe 3.0 lanes and a DMI 3.0 interface. Storage connectivity includes four SATA III ports, while USB options include ten USB 3.2 Gen 2 ports, ten USB 3.2 Gen 1 ports, and fourteen USB 2.0 ports. Integrated networking features include an integrated MAC for Ethernet and Intel Wireless-AC MAC for Wi-Fi. The chipset supports Intel Rapid Storage Technology, vPro, and Intel Standard Manageability, but does not support CPU or memory overclocking. It is intended for embedded applications and does not support Intel Optane Memory.
Specifications
| Socket | BGA 1787 |
|---|---|
| Platform unverified | Tiger Lake |
| TDP | 2.9 W |
| PCIe version | 3.0 |
| Total PCIe lanes (chipset) | 20 |
| DMI version | 3.0 |
| Memory support | DDR4-3200 |
| Max memory | 64 GB |
| Memory channels | 2 |
| ECC memory support | No |
| SATA III ports | 4 |
| USB 3.2 Gen 2 ports | 10 |
| USB 3.2 Gen 1 ports | 10 |
| USB 2.0 ports | 14 |
| Integrated Ethernet | Integrated MAC |
| Integrated Wi-Fi | Intel Wireless-AC MAC |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking | No |
| Memory overclocking (XMP/EXPO) | No |
| Release date | 2021-07-01 |
| Release year | 2021 |
| Launch MSRP | 56 USD |
| Notes | Embedded chipset; supports Intel Optane Memory: No; supports Intel Standard Manageability: Yes |
