Intel QM67
The Intel QM67 is a mobile chipset for Socket G2, released in 2011. It supports DDR3-1333 memory up to 16 GB and features 6 SATA III ports.
The Intel QM67 is a mobile chipset introduced in 2011 for the Socket G2 platform. It is built on a 32 nm process with a TDP of 3.9 W. The chipset supports DDR3-1333 memory in dual-channel configuration up to 16 GB, without ECC support. It provides 8 PCIe 2.0 lanes and 14 USB 2.0 ports, but lacks USB 3.0 and Thunderbolt. Storage connectivity includes 6 SATA III ports. The QM67 integrates Intel Rapid Storage Technology and vPro support, but does not allow CPU or memory overclocking. It is designed for BGA form factors and was succeeded by the QM77 in 2012.
Specifications
| Socket unverified | Socket G2 |
|---|---|
| Platform | Mobile |
| Process node | 32 nm |
| TDP unverified | 3.9 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3-1333 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 2x2 ports unverified | 0 |
| USB 3.2 Gen 2 ports unverified | 0 |
| USB 3.2 Gen 1 ports unverified | 0 |
| USB 2.0 ports | 14 |
| Thunderbolt support unverified | No |
| Integrated Ethernet | No |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| CPU overclocking unverified | No |
| Memory overclocking (XMP/EXPO) unverified | No |
| Supported form factors unverified | BGA |
| Release date unverified | 2011-02-20 |
| Release year unverified | 2011 |
| Discontinued | 2015-10-01 |
| Launch MSRP unverified | 40 USD |
| Successor unverified | QM77 |
| Predecessor unverified | QM57 |
