Intel QM77
The Intel QM77 is a mobile chipset released in 2012, designed for Intel's third-generation Core processors.
The Intel QM77 is a mobile chipset introduced in 2012, part of the Intel 7 Series family. It uses a BGA 1224 socket and is built on a 22 nm process with a TDP of 4.1 W. The chipset supports DDR3/L/-RS memory at 1333/1600 MHz, up to 16 GB across two channels, without ECC support. It provides 8 PCIe 2.0 lanes and uses DMI 2.0 for connection to the CPU. Storage includes 6 SATA III ports, and connectivity includes 4 USB 3.2 Gen 1 ports and 10 USB 2.0 ports. It features Intel Rapid Storage Technology and vPro support. This chipset is used with mobile processors of the Ivy Bridge generation.
Specifications
| Socket unverified | BGA 1224 |
|---|---|
| Platform | Mobile |
| Process node unverified | 22 nm |
| TDP | 4.1 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3/L/-RS 1333/1600 |
| Max memory unverified | 16 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 1 ports | 4 |
| USB 2.0 ports | 10 |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Release date unverified | 2012-04-08 |
| Release year | 2012 |
