Intel · 2013
Intel QM87
The Intel QM87 is a mobile chipset released in 2013, designed for Intel Haswell processors with BGA 1364 socket.
The Intel QM87 is a mobile chipset introduced in June 2013 for Intel's Haswell platform. It is built on a 32 nm process with a TDP of 2.7 W and supports up to 32 GB of DDR3L memory at 1333/1600 MHz across two channels. The chipset provides 8 PCIe 2.0 lanes, 6 SATA III ports, 6 USB 3.2 Gen 1 ports, and 8 USB 2.0 ports. It features Intel Rapid Storage Technology and vPro support, but lacks Thunderbolt and integrated Ethernet. The QM87 is paired with Haswell mobile processors and was discontinued in December 2015.
Specifications
| Socket unverified | BGA 1364 |
|---|---|
| Platform | Mobile |
| Process node | 32 nm |
| TDP | 2.7 W |
| PCIe version | 2.0 |
| Total PCIe lanes (chipset) | 8 |
| DMI version unverified | 2.0 |
| Memory support unverified | DDR3L 1333/1600 |
| Max memory unverified | 32 GB |
| Memory channels unverified | 2 |
| ECC memory support unverified | No |
| SATA III ports | 6 |
| USB 3.2 Gen 2x2 ports | 0 |
| USB 3.2 Gen 2 ports | 0 |
| USB 3.2 Gen 1 ports | 6 |
| USB 2.0 ports | 8 |
| Thunderbolt support unverified | No |
| Integrated Ethernet | No |
| Intel Rapid Storage Technology | Yes |
| vPro support | Yes |
| Release date | 2013-06 |
| Release year | 2013 |
| Discontinued | 2015-12 |
